Hamm HD 14i TT
| Make | Hamm |
| Model | HD 14i TT |
| Type | Series HD CompactLine |
How can we help?
Description
-
Simple transport, simple loading
-
Excellent view of tires, machine and construction site
-
Compact dimensions
-
Simple, intuitive and language-neutral control
-
Ergonomic driver platform
Specifications
- BASIC DATA - Description: Tandem roller with two sets of wheels
- BASIC DATA - Exhaust emissions category: EU Stage V / EPA Tier 4
- BASIC DATA - Name: HD 14i TT
- BASIC DATA - Series: HD CompactLine
- DIESEL ENGINE - Cylinders, quantity: 4
- DIESEL ENGINE - Exhaust emission standard: EU Stage V / EPA Tier 4
- DIESEL ENGINE - Exhaust gas after-treatment: DOC-DPF
- DIESEL ENGINE - Manufacturer: KUBOTA
- DIESEL ENGINE - Model: V2403-CR-E5B
- DIESEL ENGINE - Power ISO 14396, HP: 50 HP
- DIESEL ENGINE - Power ISO 14396, kW: 36.8 kW
- DIESEL ENGINE - Power ISO 14396, rpm: 2,700 rpm
- DIESEL ENGINE - Power SAE J1995, HP: 50.1 hp
- DIESEL ENGINE - Power SAE J1995, kW: 37.4 kW
- DIESEL ENGINE - Power SAE J1995, rpm: 2,700 rpm
- MACHINE DIMENSIONS - Center distance: 76.8 in
- MACHINE DIMENSIONS - Ground clearance, center: 12 in
- MACHINE DIMENSIONS - Maximum working width: 50.2 in
- MACHINE DIMENSIONS - Total height with cab: 107.1 in
- MACHINE DIMENSIONS - Total height with ROPS: 102 in
- MACHINE DIMENSIONS - Total length: 116.7 in
- MACHINE DIMENSIONS - Total width: 51 in
- MACHINE DIMENSIONS - Turning radius, inside: 102.4 in
- SOUND LEVEL - Acoustic power LW(A), measured: 100 db(A)
- SOUND LEVEL - Sound power level L(WA), guaranteed: 101
- STEERING - Oscillation angle +/-: 8 °
- STEERING - Steering, type: Articulated steering
- TANK CAPACITY/FILLING CAPACITY - Additive tank, capacity: 4.8 gal
- TANK CAPACITY/FILLING CAPACITY - Fuel tank, capacity: 19.3 gal
- TANK CAPACITY/FILLING CAPACITY - Water tank, capacity: 68.7 gal
- TIRE DIMENSIONS - Number of tires, front: 3
- TIRE DIMENSIONS - Number of tires, rear: 4
- TIRE DIMENSIONS - Tire size, front: 10.5
- TIRE DIMENSIONS - Tire size, rear: 80-16
- TIRE DIMENSIONS - Width over tires, front: 44.4 in
- TIRE DIMENSIONS - Width over tires, rear: 50.2 in
- TRAVEL DRIVE - Gradeability: 40 %
- TRAVEL DRIVE - Speed, infinitely variable: 0,0-6,2
- WATER-SPRINKLING SYSTEM - Water sprinkling, type: Pressure
- WEIGHTS - Axle load, front: 3,704 lbs
- WEIGHTS - Axle load, rear: 4,112 lbs
- WEIGHTS - Empty weight without cab, without ROPS: 7,067 lbs
- WEIGHTS - Operating weight with cab: 8,478 lbs
- WEIGHTS - Operating weight with ROPS: 7,817 lbs
- WEIGHTS - Wheel load per tire, front: 1,235 lbs
- WEIGHTS - Wheel load per tire, rear: 1,028 lbs
