Vogele Super 800i

Mini Class

How can we help?

(208) 324-2900

Thanks to its compact design, variable pave width and high performance, the SUPER 700i is the ideal mini paver for surfacing footpaths and cycle paths, as well as for minor paving jobs and pavement repairs. Its excellent value for money and particularly simple operating concept make the SUPER 700i an ideal partner for garden and landscaping contractors, as well as for municipal authorities.

Features

ErgoBasic: ErgoBasic was designed on the back of the tried and tested ErgoPlus operating system for our Premium Line pavers and tailored specifically to meet the demands and needs of VÖGELE Classic Line users. The goal was to develop an operating system which can be operated just as quickly, accurately and intuitively as the ErgoPlus 3 system on the “Dash 3” machines. That makes VÖGELE the only manufacturer to offer a standardized operating concept for all paver classes.
Niveltronic Basic: VÖGELE has also developed the Niveltronic Basic System for Automated Grade and Slope Control to match the ErgoBasic operating concept. It is completely integrated in the machine control system and therefore perfectly adapted to the paver model concerned. Another outstanding aspect of Niveltronic Basic is its particularly simple and intuitive handling, a feature which makes it easy even for less experienced operators to use the system correctly. This creates ideal conditions for the Classic Line pavers to work true to line and level on any base.

Specifications

Augers :	2
Augers Diameter:	300 mm
Augers Drive:	separate hydraulic drives, proportional control
Augers Height:	infinitely variable
Augers Speed:	70 U/min
Augers Standard height:	mechanically adjustable by 10 cm
Augers Version:	auger rotation reversible, mounted overhung
Conveyors :	1
Conveyors Drive:	separate hydraulic drives, proportional control
Conveyors Speed:	31 m/min
Conveyors Version:	with replaceable feeder bars, direction of conveyor temporarily reversible
Drive ECO mode output:	54 kW / 1800 U/min
Drive Emission Daily noise exposure level :	80 dB
Drive Emission Sound power level :	104 dB
Drive Engine:	liquid-cooled 4-cylinder diesel engine
Drive Exhaust emissions after-treatment:	DOC, DPF
Drive Exhaust emissions standard:	European exhaust emissions standard V, US standard EPA Tier 4f
Drive Fuel tank:	80 l
Drive Manufacturer :	Deutz
Drive Nominal output:	55.4 kW / 2200 U/min
Drive Type:	TCD 2.9 L4
Length Screed :	AB 220 V
Length Total:	4.4 m
Material Hopper Feed height (bottom of material hopper):	590 mm
Material Hopper Hopper capacity:	5.8 t
Material Hopper Push-Rollers Positions :	can be adjusted in a forward direction by 100 mm and left by 500 mm
Material Hopper Push-Rollers Standard:	oscillating, fold up with hopper sides
Material Hopper Width:	2,900 mm
Maximum Laydown Rate:	300 t/h
Operating Total Weight:	6,200 kg
Operating Weight Screed:	AB 220 V
Screed Basic width :	1.2 m
Screed Compacting systems:	TV
Screed Heating:	electric
Screed Layer thickness (up to):	20 cm
Screed Maximum width :	3.5 m
Screed Power Supply:	Three-phase AC generator
Screed Type:	AB 220
Undercarriage Crawler tracks:	provided with rubber pads
Undercarriage Ground contact:	1500 mm x 180 mm
Undercarriage Lubrication of track rollers:	lifetime
Undercarriage Speeds Pave speed crawler tracks (up to):	30 m/min
Undercarriage Speeds Travel speed (up to):	3.6 km/h
Undercarriage Track tension adjuster:	spring assembly
Undercarriage Traction drive crawler tracks:	separate hydraulic drives with electronic control

Links

Features
Features
- ErgoBasic: ErgoBasic was designed on the back of the tried and tested ErgoPlus operating system for our Premium Line pavers and tailored specifically to meet the demands and needs of VÖGELE Classic Line users. The goal was to develop an operating system which can be operated just as quickly, accurately and intuitively as the ErgoPlus 3 system on the “Dash 3” machines. That makes VÖGELE the only manufacturer to offer a standardized operating concept for all paver classes.
- Niveltronic Basic: VÖGELE has also developed the Niveltronic Basic System for Automated Grade and Slope Control to match the ErgoBasic operating concept. It is completely integrated in the machine control system and therefore perfectly adapted to the paver model concerned. Another outstanding aspect of Niveltronic Basic is its particularly simple and intuitive handling, a feature which makes it easy even for less experienced operators to use the system correctly. This creates ideal conditions for the Classic Line pavers to work true to line and level on any base.

Specifications

Augers :	2
Augers Diameter:	300 mm
Augers Drive:	separate hydraulic drives, proportional control
Augers Height:	infinitely variable
Augers Speed:	70 U/min
Augers Standard height:	mechanically adjustable by 10 cm
Augers Version:	auger rotation reversible, mounted overhung
Conveyors :	1
Conveyors Drive:	separate hydraulic drives, proportional control
Conveyors Speed:	31 m/min
Conveyors Version:	with replaceable feeder bars, direction of conveyor temporarily reversible
Drive ECO mode output:	54 kW / 1800 U/min
Drive Emission Daily noise exposure level :	80 dB
Drive Emission Sound power level :	104 dB
Drive Engine:	liquid-cooled 4-cylinder diesel engine
Drive Exhaust emissions after-treatment:	DOC, DPF
Drive Exhaust emissions standard:	European exhaust emissions standard V, US standard EPA Tier 4f
Drive Fuel tank:	80 l
Drive Manufacturer :	Deutz
Drive Nominal output:	55.4 kW / 2200 U/min
Drive Type:	TCD 2.9 L4
Length Screed :	AB 220 V
Length Total:	4.4 m
Material Hopper Feed height (bottom of material hopper):	590 mm
Material Hopper Hopper capacity:	5.8 t
Material Hopper Push-Rollers Positions :	can be adjusted in a forward direction by 100 mm and left by 500 mm
Material Hopper Push-Rollers Standard:	oscillating, fold up with hopper sides
Material Hopper Width:	2,900 mm
Maximum Laydown Rate:	300 t/h
Operating Total Weight:	6,200 kg
Operating Weight Screed:	AB 220 V
Screed Basic width :	1.2 m
Screed Compacting systems:	TV
Screed Heating:	electric
Screed Layer thickness (up to):	20 cm
Screed Maximum width :	3.5 m
Screed Power Supply:	Three-phase AC generator
Screed Type:	AB 220
Undercarriage Crawler tracks:	provided with rubber pads
Undercarriage Ground contact:	1500 mm x 180 mm
Undercarriage Lubrication of track rollers:	lifetime
Undercarriage Speeds Pave speed crawler tracks (up to):	30 m/min
Undercarriage Speeds Travel speed (up to):	3.6 km/h
Undercarriage Track tension adjuster:	spring assembly
Undercarriage Traction drive crawler tracks:	separate hydraulic drives with electronic control

Downloads & Documentation
Links
- Brochure SUPER 800i
