John Deere Hammers
| Make | John Deere |
| Model | Hammers |
| Type | Worksite Pro Construction Attachments |
How can we help?
Description
Optimized for use with John Deere equipment but compatible with most competitive models, our hydraulic hammers make an impact on jobs big and small. From landscaping to trenching, these hydraulic breakers deliver big productivity. Models HH20C-HH80C pair easily with our backhoes and compact construction equipment, including skid steers, compact track loaders, and mini excavators. Models HH90-HH145 are compatible with our mid-sized and large excavators.
Models
Hammers for Compact Equipment
| Model | Weight | Operating Pressure | Pressure Relief | Impact Rate |
|---|---|---|---|---|
|
HH20C Hammer |
150 kg (270 lb.) |
90–150 bar (1,305–2,175 psi) |
220 bar (3,190 psi) |
800–3,000 blows/min. |
|
HH40C Hammer |
190 kg (420 lb.) |
100–170 bar (1,450–2,465 psi) |
220 bar (3,190 psi) |
700–2,600 blows/min. |
|
HH60C Hammer |
228 kg (500 lb.) |
80–130 bar (1,160–1,885 psi) |
220 bar (3,190 psi) |
600–1,800 blows/min. |
|
HH80C Hammer |
315 kg (690 lb.) |
90–140 bar (1,305–2,030 lb.) |
220 bar (3,190 psi) |
500–1,700 blows/min. |
Hammers for Mid-Sized & Large Excavators
| Model | Impact Energy Class | Weight | Operating Pressure | Impact Rate |
|---|---|---|---|---|
|
HH90 Hammer |
1627 J (1,200 ft.-lb.) |
500 kg (1,100 lb.) |
10-14 MPa (1,450-2,030 psi) |
500-1,700 blows/min. |
|
HH115 Hammer |
3390 J (2,500 ft.-lb.) |
1,100 kg (2,430 lb.) |
13.5-14.5 MPa (1,960-2,105 psi) |
540-920 blows/min. |
|
HH125 Hammer |
4745 J (3,500 ft.-lb.) |
1,360 kg (3,000 lb.) |
14-16 MPa (2,030-2,320 psi) |
430-790 blows/min. |
|
HH135 Hammer |
6779 J (5,000 ft.-lb.) |
1,670 kg (3,680 lb.) |
13.5-14.5 MPa (1,960-2,105 psi) |
450-750 blows/min. |
|
HH145 Hammer |
10 847 J (8,000 ft.-lb) |
2,350 kg (5,180 lb.) |
15-16 MPa (2,175-2,320 psi) |
37-630 blows/min. long stroke |
Features
- Hammers for Compact Equipment: These are the fastest hydraulic hammers on the market, with 30-percent fewer parts than either competitive or previous models, for simplified maintenance. Redesigned to provide two to three times more blows per minute (BPM) than previous models, for increased efficiency. Exclusive tool retention enables quick installation and removal using only one small screwdriver.
- Hammers for Mid-Sized & Large Excavators: Whether you’re looking for an efficient alternative to a wrecking ball on a big demolition job or need to break up materials for landscaping, trenching, recycling, or other applications, John Deere excavator-compatible hydraulic hammers deliver breakthrough performance. Optimized for Deere excavators, they are also compatible with most competitive models.
- Quik-Tatch: With our universal, self-cleaning Quik-Tatch easy-attachment system, you can switch from one type of attachment to another in no time flat.
